Home > Switching Power Adapters >

11W KSAS010 Series Ktec Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box

Product Categories

HONG KONG BESTWAY CO.LTD (SHENZHEN ALL-KEY TECHNOLOGY CO. LTD)

Contact Now

11W KSAS010 Series Ktec Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box

Place of Origin : China Mainland

Certification : CB , GS , CE , TUV, UL , CCC , FCC,PSE,KC,C-TICK

Model Number : 11W KSAS010 Series

MOQ : 1000PCS

Price : Negotiable

Packaging Details : PE bag + White box

Delivery Time : 35 days

Payment Terms : T/T

Supply Ability : 1Million/Month

Contact Now

11W KSAS010 Series Ktec Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box

Brand Name:	•ktec
Input:	•Input Voltage: 90 to 264 VAC •Frequency : 47-50/60-63HZ •Input Current : 0.4A (Max) 100/240VAC •Inrush Current : 60A Max 100VAC at max Load 100A Max 240VAC at max Load •Leakage Current: 0.25mA Max
Output:	•Over voltage protection •Over current protection at 110-250% of lo and Auto-recovery •Electronic short circuit protection •Operating temperature 0~40℃ Free convection •Operating humidity 10-90% RH Non Condensing •Sea level Non-operating temperature -20~ 80℃
Safety standards:	•Information technology equipment •IEC/EN 60950-1, UL 60950-1, CSA C22.2 No. 60950-1-03, GB4943
Certificates and approvals:	•CB , GS , CE , TUV, UL , CCC , FCC,PSE,KC,C-TICK
EMI Emission:	•Radiation Test&Conduction Test:EN 55022/FCC Part 15 •Harmonic Test: EN 61000-3-2 •Flicker Test: EN 61000-3-3
EMS immunity:	•ESD Test:EN 61000-4-2 •RS Test:EN 61000-4-3 •EFT Test:EN 61000-4-4 •Surge Test:EN 61000-4-5 •CS Test:EN 61000-4-6 •DIP Test:EN 61000-4-11
Key Applications:	Key Features of KSAS010 series •Light, extra slim, sleek, compact design •Green power, full complies with CEC level V, MEPS IV EUP2011 •High power density •Extra safe design, have got their respective safety approvals •Completed protect function Key Applications of KSAS010 series •It’s suitable for an extremely wide range of applications, including: •Mobile Devices •ADSL •Pos •Audio & Video product •Set-top-box •Household appliance
Payment Details:	•Payment Terms: T/T,negotiable for OEMs
Main Export Markets:	• Eastern Europe • North America • Mid East/Africa • Central/South America • Asia • Western Europe • Australasia

11W KSAS010 Series Ktec Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box

Product Tags:

switching power supply adapter

switching adaptor power supply

Wholesale 11W KSAS010 Series Ktec Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box from china suppliers

11W KSAS010 Series Ktec Switching Power Adapters With Wide Range For General I.T.E Use, Set-top-box Images
